|  | Topic : Kuryakyn Metric Adapters for Triumph |  |
| | | Terota66 | | Chaac |  |  | | Reg. Date | : | 24/11/2013 | | Posts | : | 505 | | Location | : | Nova Scotia, Canada |
|
| | Posted : 25 Jan 2014 - 22:17 Post title : Kuryakyn Metric Adapters for Triumph | | | Kuryakyn 8840 & 8802 Metric Adapters for Triumph
I've purchased these for my 2013 Storm, problem is the front ones have way to much play on them, rear ones fit perfectly I've made a plastic ring to make up for it.........anyone else have this problem?
| 2013 Thunderbird Storm ABS
HardStreets
LED Headlights
Short Tors & tune
K&N air filter
Mustang Vintage 2 Up Seat
Scorpion Alarm
| | Post edited by Terota66 on 25 Jan 2014 - 22:18 |
|
| | | BluesDrummer | | Set | |  | | Reg. Date | : | 20/11/2010 | | Posts | : | 95 | | Location | : | Des Moines, Iowa, United States |
|
| | Posted : 25 Jan 2014 - 23:05 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: Terota66) | | | Fast Eddy sells an "Adapters Pin Adapter" that I believe is just for this purpose.
Link
|
|
| | | Terota66 | | Chaac | | | | Reg. Date | : | 24/11/2013 | | Posts | : | 505 | | Location | : | Nova Scotia, Canada |
|
| | Posted : 26 Jan 2014 - 00:07 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: BluesDrummer) | | | Thanks Blues, I was just on that page looking at "things to buy" and must have rolled over that a few times......
| 2013 Thunderbird Storm ABS
HardStreets
LED Headlights
Short Tors & tune
K&N air filter
Mustang Vintage 2 Up Seat
Scorpion Alarm
|
|
| | | PapaSmurfMC | | Chaac | |  | | Reg. Date | : | 03/10/2013 | | Posts | : | 871 | | Location | : | Philadelphia, Pennsylvania, United States |
|
| | Posted : 26 Jan 2014 - 02:13 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: Terota66) | | | I used Eddy's MM07 Pin Adapters with the Kury 8840 peg adapters on my Dually install and I highly recommend them.
I found that I had to mount the Kuryakyn 8840 peg adapters 180 degrees out of phase between the left and right sides for them to sit level on both sides. The 8840 peg adapters have a little lip on one side, presumably to act as a stop but as far as I can tell, they're completely unnecessary and don't serve any purpose on the TBird. On the right side with the lip facing down, the adapter woudn't sit flush with the TBird's peg bracket (it was angled up a few degrees) because the radius of the adapter lip wasn't clearing the edge of the peg bracket. I flipped the adapter over and all was well.
You can see my Dually install at Link
| 2013 Blue Marble Haze Thunderbird 1600 ABS
2009 Black Bonneville A1 ("Mag")
Buncha farkles
|
|
| | | Terota66 | | Chaac | | | | Reg. Date | : | 24/11/2013 | | Posts | : | 505 | | Location | : | Nova Scotia, Canada |
|
| | Posted : 26 Jan 2014 - 03:04 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: PapaSmurfMC) | | | wow, thanks PapaSmurf .......very detailed fix, I to hate the look of floorboards, I bought the zombie pegs and now I don't really care for them, I find I'm going on longer drives and would like more comfort ........love the set up, how would you rate your set up to lets say Kuryakyn Switchblade Footpegs ? Link
Before I put in another order with FastEddy
| 2013 Thunderbird Storm ABS
HardStreets
LED Headlights
Short Tors & tune
K&N air filter
Mustang Vintage 2 Up Seat
Scorpion Alarm
| | Post edited by Terota66 on 26 Jan 2014 - 03:05 |
|
| | | PapaSmurfMC | | Chaac | | | | Reg. Date | : | 03/10/2013 | | Posts | : | 871 | | Location | : | Philadelphia, Pennsylvania, United States |
|
| | Posted : 26 Jan 2014 - 03:23 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: Terota66) | | | Terota66 wrote:
........love the set up, how would you rate your set up to lets say Kuryakyn Switchblade Footpegs ?
Before I put in another order with FastEddy |
|
I haven't used the Switchblades but the Kury stirrups look a lot sturdier. The advantage of the Switchblades is that since they're part of the peg, there's no rotation issue to deal with so they're easier to mount. On the other hand, you can't adjust the angle of the heel rest independently of the peg and I have read of an incident where the Switchblades folded up in use.
I put the Dually/stirrup combo on my previous bike and really liked it. The rotation issue is a real PITA but it can be fixed.
| 2013 Blue Marble Haze Thunderbird 1600 ABS
2009 Black Bonneville A1 ("Mag")
Buncha farkles
| | Post edited by PapaSmurfMC on 26 Jan 2014 - 03:38 |
|
| | | Terota66 | | Chaac | | | | Reg. Date | : | 24/11/2013 | | Posts | : | 505 | | Location | : | Nova Scotia, Canada |
|
| | Posted : 26 Jan 2014 - 03:40 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: PapaSmurfMC) | | | I agree, your set up looks a lot sturdier, placed a small order with fast eddy and asked if he could get me almost the same set up, going to buy the 7562 GLOSS BLACK ISO PEGS with the stirrups instead (as much black on my bike as possible)
| 2013 Thunderbird Storm ABS
HardStreets
LED Headlights
Short Tors & tune
K&N air filter
Mustang Vintage 2 Up Seat
Scorpion Alarm
|
|
| | | hairdoo | | Set | |  | | Reg. Date | : | 11/08/2013 | | Posts | : | 159 | | Location | : | haymarket, va, United States |
|
| | Posted : 26 Jan 2014 - 11:36 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: Terota66) | | | FWIW, I had dually's with stirrups on my america, which I had a couple of years, and absolutely loved that set up. it was extremely comfortable. I solved the rotation issue within the first 2 days; each time they rotated a little, I stopped and tightened them some - eventually they stopped rotating. Yet I could get them on and off easily. I considered it a "break in" process.
|
|
| | | GerPa | | Jupiter | |  | | Reg. Date | : | 10/12/2011 | | Posts | : | 1,919 | | Location | : | Mackay, Central Queensland, Australia |
|
| | Posted : 26 Jan 2014 - 12:04 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: hairdoo) | | | I had the same problem with them on My America and I could never get them tight enough. I even lapped both surfaces. Thus KY Switchblades for the TBird are the best answer.
|  May-2011-1600, 20306 Tune, Mustang Vintage Solo Seat, Meerkat Cat Bypass, + Meerkat Modified Short TORS   ,K&N Air Cleaner,K&N Oil Filter, JBQ lifting system, Gold Plug Magnetic Sump Plug,Dart Fly screen, Rivco Risers, GiPro Gear Indicator, Breakaway Cruise Control, Avon ISO Grips, Scorpion Western Low Handlebars, Kury Switchblade Pegs, Garmin Zumo390LM,Michelin RC2 on Front RC 3 on ,Modified Rear Drive Pulley Hub Bearings (Mat1600/Alex4 Modification) Front Susp: Std & 7.5W Oil /126mm Air Gap & Rear:Hagon Nitro's with 26Kg/cm Springs + Lots of other "Bling" stuff.
|
|
| | | PapaSmurfMC | | Chaac | | | | Reg. Date | : | 03/10/2013 | | Posts | : | 871 | | Location | : | Philadelphia, Pennsylvania, United States |
|
| | Posted : 27 Jan 2014 - 02:05 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: GerPa) | | |
GerPa wrote:
I had the same problem with them on My America and I could never get them tight enough. I even lapped both surfaces. Thus KY Switchblades for the TBird are the best answer. |
|
There were some peg adapters that were a touch shallow and the bolt that ran through the peg and stirrup into the adapter would bottom out, preventing the whole assembly from being tightened as much as needed. Hacking a few mm off of the bolt solved that problem.
The peg and stirrup combo was a great idea poorly engineered by Kuryakyn. The support guy I spoke to offered no excuses; you could tell they were embarrassed by it.
| 2013 Blue Marble Haze Thunderbird 1600 ABS
2009 Black Bonneville A1 ("Mag")
Buncha farkles
|
|
| | | Smitty | | Chaac | |  | | Reg. Date | : | 01/10/2012 | | Posts | : | 996 | | Location | : | Hawkesbury, NSW, Australia |
|
| | Posted : 27 Jan 2014 - 09:39 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: PapaSmurfMC) | | |
PapaSmurfMC wrote:
You can see my Dually install at Link
|
|
Hey PapaSmurf, did you gain or lose any ground clearance (peg scraping) with the new pegs and stirrups ???
Cheers Smitty
| Cheers Smitty
2013 Matt Graphite Storm, Foran Razorbacks, Hagon shocks & springs.
I don't get angry, I get even
|
|
| | | PapaSmurfMC | | Chaac | | | | Reg. Date | : | 03/10/2013 | | Posts | : | 871 | | Location | : | Philadelphia, Pennsylvania, United States |
|
| | Posted : 28 Jan 2014 - 04:59 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: Smitty) | | | Smitty wrote:
Hey PapaSmurf, did you gain or lose any ground clearance (peg scraping) with the new pegs and stirrups ???
Cheers Smitty |
|
The Dually/stirrup combo is a little longer than the stock peg so maybe that means a tiny loss but the underside of the Dually is a clean 11 inches off the ground and the stirrup is only 1 inch lower (but in 4 inches closer to the bike so the tip would still hit first). The Bird's a little large to be dragging a knee but there's plenty of clearance.
| 2013 Blue Marble Haze Thunderbird 1600 ABS
2009 Black Bonneville A1 ("Mag")
Buncha farkles
| | Post edited by PapaSmurfMC on 28 Jan 2014 - 05:04 |
|
| | | Smitty | | Chaac | | | | Reg. Date | : | 01/10/2012 | | Posts | : | 996 | | Location | : | Hawkesbury, NSW, Australia |
|
| | Posted : 28 Jan 2014 - 07:33 Post title : Re: Kuryakyn Metric Adapters for Triumph (Re: PapaSmurfMC) | | |
PapaSmurfMC wrote:
Smitty wrote:
Hey PapaSmurf, did you gain or lose any ground clearance (peg scraping) with the new pegs and stirrups ???
Cheers Smitty |
|
The Dually/stirrup combo is a little longer than the stock peg so maybe that means a tiny loss but the underside of the Dually is a clean 11 inches off the ground and the stirrup is only 1 inch lower (but in 4 inches closer to the bike so the tip would still hit first). The Bird's a little large to be dragging a knee but there's plenty of clearance.
|
|
Thanks for that, i'm just over scraping my pegs and my boots every second corner and am looking for some options....
I'm replacing the rear shocks this week and going 10mm longer than stock, hope that helps a bit....
Not concerned about dragging my knee, the sliders hold up nicely
When life throws you a curve, you may as well lean into and get your knee down
| Cheers Smitty
2013 Matt Graphite Storm, Foran Razorbacks, Hagon shocks & springs.
I don't get angry, I get even
|
|
|
| |
| |
|
